When should you get free DFA analyses? As soon as you start your design!
How often should you get it done?
- Whenever you’ve added a few more key components.
- When you’ve made a significant change to the geometry of your PCB.
Why is this service is being offered free of charge? In the long run, it saves significant time and reduces complications for both your team and ours.
An analysis provides notes and comments on:
- The ease to hold the PCB in place during the process
- The information provided to ensure proper assembly such as polarity and location of the first pin
- Component layout for stencil fabrication
- Reflow profiles for single or double sided assembly
- Assembly of throughole components
The analysis also comes with a Rough Order of Magnitude (ROM) for the following:
- Stencil Fabrication
- Setup Cost
- Assembly job
See our Assembling Capabilities here.
